Adopt strengthened driving system, steady running, easy maintenance.

Motor with inverter, available for steady, power saving, stable working.

Carrier adjustment adopt electric mode, more convenient.

Paper is fed by several thick belts, which are driven by an independent motor, with help of vibration motor and induced draft motor.

Adopt grinding motors at both sides, making gluing stable and firm.

Two sets of gluing units: Top gluing unit for bottom glue and Lower unit for side glue. It applys line glue, available to adjust by tooth rod.

PLC andtouch screen for easy operation.

Conveyor unit adopt pneumatic design.

In pre-folding unit, 1st fold at 180°, 3rd fold at 135°. In folding unit, 2nd & 4th fold at 180°, Correction system, desiened for corrugated boxes,helps paper running and folding in right lines.

For corrugated boxes, it is equipped with individual speed regulating device which can control side belt speed in each side solely in folding section, side belts can run at different speed, achieve correction of the box bevel, un-symmetric folding problem, E/B flute products is finished perfect.
