Full computer control, easy operation, stable quality, and greatly saving manpower.

Gluing integrates stitching, can glue boxes, stitch boxes, or gule plus stitch for each feeding.

Order memory function: Within 3-5 minutes, you can complete the order setting change and start mass production.

To glue or to stitch,can transfer just by one click by button.

Suitable for three-layer, five layer, and single piece paperboard AB.C and AB corrugated board stitching together.

There is a side tapping device during paper feeding to ensure neat and smooth paper feeding.

A bottomless box with a lid can also be done.

Range of stitch spacing: The minimum stitch spacing is 20mm, and the maximum range is 500mm.

Maximum stitching speed of the stitching head: 1200 stitches per minute.

Using three stitches as an example, the maximum speedreaches 150 pieces per minute.

Automatically complete paper folding, correction, box stitching, pasting, counting and stacking output work.

Single stitch or double can be freelyadjusted.

Adopting a swingimg stitching head, which fealures with low power consumption,faster speed and greater stabiliy, efiectively improvng the stitching quality.

Adopting a paper aligming coection device for secondary compensation and coreclion of box sheet misaligument. eliminating the scissors mouth.

The stitching pressure can be automatically adjusted accordingto the thickness ofthe cardboard.

The automatic wire feeder can achieve wire detection, wire breakage detection, and wire exhaustion detection.
